Components: HF: 2*1.4"(Neodymium, voice coil Φ 2.5")
MF: 4*6.5"(Neodymium)
LF: 2*12"(Neodymium)
Nominal Impedance: HF/MF/LF--8Ω/8Ω/16Ω
RMS Power Handling: HF/MF/LF--2*80W/4*150W/2*400W
Frequency Response: 50Hz-18KHz(-10dB) 3
Crossover Point: ---- ----
Sensitivity(1W/1M): LF-105 dB, MF-110 dB, HF-116 dB 104 dB
Max. SPL: 129 dB
Dispersion(HxV): 120°x8° ----
Dimensions(HxWxD): 368x966x556mm
Carton Dimensions: 1060x650x458mm
Flight Case Dimensions: 1110x620x955mm
Net Weight(Kg): 49 100
Connector: 2xNL8MPR
