Technical Parameters:
Rated voltage (V) 110VAC 240VAC 240VAC
Storage temperature (°C) -40 25 105
Working environment temperature(°C) 0 25 45
Working environment humidity (%) 0.0 10 90
Working power (W) 11
System function list
DVI INPUT
Interface form: DVI-I socket
Signal standard: DVI1.0, HDMI1.3 backward compatible
Resolution: VESA standard, PC to 1920x1200, HD to 1080p
http://www.huidu.cn/ 5
HDMI INPUT
Interface form: HDMI-A
Signal standard: HDMI1.3 backward compatible
Resolution: VESA standard, ≤ 1920 × 1200, HD to 1080p
VGA INPUT
Interface form: DB15 socket
Signal standard: R, G, B, Hsync, Vsync: 0 to 1Vpp ± 3dB (0.7V Video
+ 0.3v Sync )
75 ohm black level: 300mV Sync-tip: 0V
Resolution: VESA standard, ≤ 1920 × 1200 @ 60Hz
Composite video
input
（video）
Interface form: BNC
Signal standard: PAL/NTSC 1Vpp±3db (0.7V Video+0.3v Sync) 75 ohm
Resolution: 480i, 576i
USB playback input
2 (2 select 1) video standard: 1280x720@60Hz (rm, rmvb, mp4, mov,
mkv, wmv, avi, 3gp);
Image standard: jpg, jpeg, png, bmp.
DVI video output
2×DVI
Interface form: DVI-I socket
Signal standard: DVI standard: DVI1.0 VGA standard: VESA
Resolution: 1024×768@60Hz 1920×1080@60Hz
1024×1280@60Hz 1920×1200@60Hz
1280×1024@60Hz 1920×1280@60Hz
1600×1200@60Hz
weight 3.5kg
Case size: (length) 440mm* (width) 250mm* (height) 58mm
