Video input:
Quantity / signal type: 4-way composite video PAL/NTSC 1Vpp±3db (0.7V Video+0.3v Sync )
75 ohm
2-way VGA VESA standard, up to 1920x1200@60Hz
2-way DVI VESA standard, up to 1920x1200@60Hz
4-channel HDMI VESA standard, up to 1920x1200@60Hz
1-way SDI (optional) 1080p 60/50/30/25/24/25 (PsF)/24 (PsF)
720p 60/50/25/24
1080i 1035i
625/525 line
Connector: 4 BNC sockets composite video input
SDI input (optional)
2 15-pin HD sockets RGB input
2 DVI-I sockets DVI input
4 HDMI sockets HDMI input
Resolution range: 640x480～1920x1080 480i/p, 576i/p, 720p, 1080i/p, 2048x1080
Point-to-point sampling
Go blanking
Video processing :
Analog sampling: 12 bits per color; 13.5 MHz standard (video)
170 MHz standard (RGB)
Digital pixel data bit depth: 8, 10 or 12 bits per channel;
2 channels for HDMI
3GHz standard (SDI)
Video output:
Quantity / signal type: 1-way VGA image conversion conversion RGBHV, RGBS,
RGsB
7-channel DVI digital video (compliant with VESA standard)
1-way SDI-LOOP SDI signal loop out (optional)
Connector: 6 DVI-I sockets DVI programming output,
1 DVI-I socket monitor output interface
1 BNC socket 1 SDI-LOOP (optional)
Weight: 4kg
Size (mm): he size of the chassis: (length, width and height) 440 × 335 × 88
