Capability
FLSH capacity: 8M Byte
Communication ports: U-Disk / RS232 serial port / network port
Color: Double-color supports red, green and yellow.
Support: seven-color,Full color can display red, green, blue, yellow, purple, cyan and white.
Program quantity: Two hundred programs are available, which can be switched by buttons or remote control.
Area quantity: Eight areas with separate zone, special effect and border
LED pixel: 512(H)×2048(W),128*8192(The resolution is1024K.)
Display contents: Text, image, time, temperature, count, animated characters, etc.
Display modes: Display in order, switch by buttons or remote control
Display effects:
1. Text, image, time, count, temperature (Module is required to be connected.), etc.;
2. Support the settings of program/area/custom borders;
3. Various action modes;
4. Over 40 special character effects;
5. Support simple animated characters;
6. Support hollow/stroked characters;
7. Support the background settings of area characters;
Function of clock:
1. Support calendar/analog clock;
2. Clockwise/counter-clockwise count;
3. The font, size, color and position can be set freely;
4. Support multiple time zones;
Expanders:
Temperature/humidity/remote control/light sensors, and wireless RF module
Automatic switch screen
Support time switch
Luminance control
Support three luminance modes
